Type 6335 Bourdon tube pressure gauge NS250, all stainless steel, connection back
Model Range: 6335
Bourdon tube pressure gauge
according to EN 837-1
all stainless steel
with Blow-out back
Accuracy 1,0
Connection back eccentric
Measuring ranges
0...0,6 bar up to 0...1600 bar
Connection
G 1/2 B in stainless steel
Options
Frontflange / Flange back
This bourdon tube pressure gauge in all stainless steel is suitable for pressure measuring at harsh application conditions in production plants for chemical industry and other comparably industrial lines.
The window is made by safety glass. As standard connection is G 1/2" available, other threads are also possible (for example high-pressure thread).
